| Category |
Electric Parts |
| Name |
MCU |
| Parts No |
21Q5-32101 |
| Machine Number |
R160LC9 R180LC9 |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT |
| Packing |
As request or standard packing |
- Key functions & working principle
| Working Principle |
1. Data Acquisition: The MCU receives analog/digital signals from onboard sensors (pressure, temperature, position, engine speed) via I/O ports and CAN bus. |
| 2. Logic Processing: Using pre-programmed control algorithms (Hyundai IPC software), it processes sensor data to calculate optimal engine load, hydraulic pressure, and actuator positions. |
| 3. Command Output: Sends calibrated signals (digital/PWM) to hydraulic solenoid valves, fuel injectors, and cooling fans to adjust system operation (e.g., increase hydraulic pressure for heavy digging, reduce engine RPM for idle). |
| 4. Fault Monitoring: Continuously checks for sensor/actuator faults (e.g., open circuits, short circuits); stores error codes in memory and triggers dashboard warnings for critical faults (e.g., low hydraulic pressure). |
| 5. Diagnostics/Updates: Communicates with Hyundai Hi-MATE tool via CAN/Ethernet for error code reading, performance data logging, and firmware updates to optimize control logic. |
| Core Functions |
1. Engine-Hydraulic Coordination: Balances engine power output with hydraulic system demand – improves fuel efficiency by 8–12% vs. non-IPC systems |
| 2. Real-Time System Control: Adjusts hydraulic valve opening/closing speed and fuel injection timing for smooth, responsive equipment operation |
| 3. Fault Detection & Reporting: Identifies sensor/actuator faults, stores error codes, and alerts operators via dashboard indicators – reduces unplanned downtime |
| 4. Performance Optimization: Adapts control logic to operating conditions (e.g., light load vs. heavy load) – maximizes productivity while minimizing component wear |
| 5. Telematics Integration: Transmits operational data (fuel usage, fault codes) to Hyundai’s remote monitoring system (Hi-Remote) – enables predictive maintenance |
9-SERIES CRAWLER EXCAVATOR R160LC9 R180LC9 Hyundai
- More other MCU applied to HYUNDAI heavey machine
| 21Q5-32102 MCU |
| R160LC9, R180LC9 |
| |
| 21N5-34100 MCU(MACHINE CNTL UNIT) |
| R160LC7A, R180LC7A |
| |
| 21Q4-32300 MCU |
| R145CR9 |
| |
| 21Q4-32201 MCU |
| R140W9 |
| |
| 21N4-34200 MCU(MACHINE CNTL UNIT) |
| R140W7A |
| |
| 21N4-43200 MCU(MACHINE CNTL UNIT) |
| R140W7 |
| |
| 21Q4-32100 MCU |
| R140LC9 |
| |
| 21N4-34100 MCU(MACHINE CNTL UNIT) |
| R140LC-7A |
| |
| 21N3-32200 MCU(MACHINE CONTL UNIT) |
| R110-7A |
| |
| 21N3-32102 MCU(MACHINE CONTROL UNIT) |
| R110-7 |
| |
| 21N3-32101 MCU(MACHINE CONTROL UNIT) |
| R110-7 |
| |
| 21LQ-34100 MCU |
| HL780-9 |
| |
| 21LQ-32101 MCU |
| HL780-9 |
| |
| 21N5-33100 MCU(MACHINE CNTL UNIT) |
| R170W7 |
| |
| 21N5-34200 MCU(MACHINE CNTL UNIT) |
| R170W7A |
| |
| 21N5-34201 MCU(MACHINE CNTL UNIT) |
| R170W7A |
| |
| 21Q5-32200 MCU |
| R170W9 |
| |
| 21N6-32410 MCU |
| R200W7 |
| |
| 21N6-32411 MCU |
| R200W7 |
| |
| 20N6-60800 MCU SUB ASSY |
| Hyundai |
| |
| 21N6-42101 MCU CONTROLLER |
| R210LC7 |
| |
| 21N6-34100 MCU(MACHINE CNTL UNIT) |
| R210LC7A |
| |
| 21N6-20021 MCU(MACHINE CNTL UNIT) |
| R210LC7H, RC215C7H |
| |
| 21Q6-32102 MCU |
| R210LC9 |
| |
| 21Q6-32101 MCU |
| Hyundai |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3 |
21Q5-10601 |
[1] |
HARNESS-FRAME |
|
| 3 |
21Q5-10602 |
[1] |
HARNESS-FRAME |
|
| 3 |
21Q5-10603 |
[1] |
HARNESS-FRAME |
|
| 3 |
21Q5-10604 |
[1] |
HARNESS-FRAME |
|
| 3-1. |
21EA-50550 |
[1] |
DIODE-IN5406 |
NOT SHOWN |
| 3-2. |
21EA-50570 |
[1] |
DIODE-FE3D |
NOT SHOWN |
| 11 |
21Q5-32101 |
[1] |
MCU(MACHINE CNTL UNIT) |
|
| 11 |
21Q5-32102 |
[1] |
MCU(MACHINE CNTL UNIT) |
|
| 12 |
21N4-01130 |
[1] |
PLATE-CLIP |
|
| 13 |
25D1-10640 |
[4] |
CLIP ASSY |
|
| 14 |
25D1-10650 |
[1] |
CLIP ASSY |
|
| 16 |
S035-082526 |
[3] |
BOLT-W/WASHER |
|
| 19 |
E127-3158 |
[1] |
BAND-FUEL PUMP |
|
| 20 |
21N4-20550 |
[1] |
HOSE-OUTLET |
|
| 21 |
21QB-60700 |
[2] |
WORK LAMP ASSY |
|
| 21-1. |
S866-240650 |
[2] |
BULB-H3,65W |
NOT SHOWN |
| 26 |
21Q4-30600 |
[1] |
HORN-HIGH |
|
| 26 |
21N5-10061 |
[1] |
HORN-HIGH |
|
| 27 |
21Q4-30500 |
[1] |
HORN-LOW |
|
| 27 |
21N5-10051 |
[1] |
HORN-LOW |
|
| 33 |
S037-102026 |
[12] |
BOLT-W/WASHER |
|
| 36 |
31L7-10190 |
[13] |
CLAMP-TUBE |
|
| 39 |
S520-032000 |
[3] |
CLAMP-HOSE |
|
| 41 |
21N6-20080 |
[1] |
PLATE-CLAMP |
|
| 47 |
S037-102526 |
[2] |
BOLT-W/WASHER |
|
| 59 |
21QB-20080 |
[1] |
PLATE-CLAMP |
|
| 90 |
21Q6-50410 |
[1] |
ADAPTER |
NOT SHOWN |
